Centrifugal party systems centrifugal party systems are a mechanical device that sucks gas from the air inlet through a high-speed rotating impeller and throws the gas out through centrifugal force to achieve gas flow. It is widely used in industrial ventilation, air conditioning and refrigeration, environmental protection and dust removal, and other fields. It is an…

Description

Centrifugal party systems

centrifugal party systems are a mechanical device that sucks gas from the air inlet through a high-speed rotating impeller and throws the gas out through centrifugal force to achieve gas flow. It is widely used in industrial ventilation, air conditioning and refrigeration, environmental protection and dust removal, and other fields. It is an indispensable and important equipment in modern industrial production and daily life.

Specification

No. Speed

(r/min)

Working condition Air Flow

(m³/h)

Total pressure

(Pa)

Moter power

(kw)

2.8A 2900 1 1330 970 1.5
3.2A 2900 2 2450 1167 2.2
3.2A 1450 3 1385 264 1.1
3.6A 2900 4 4846 1382 3
3.6A 1450 5 2350 323 1.1
4A 2900 6 7420 1340 5.5
4A 1450 1 2010 510 1.1
4.5A 2900 2 7120 2412 7.5
4.5A 1450 3 2900 578 1.1
5A 2900 4 11830 2844 15
5A 1450 5 6392 647 2.2
6A 1450 6 12720 800 4
6A 980 1 4520 510 1.5
6C 2240 3 14500 2549 15
6C 2000 3 12950 2039 11

centrifugal party systems centrifugal party systems

Working principle

Centrifugal fans are based on the principle of converting kinetic energy into potential energy. They use a high-speed rotating impeller to accelerate the gas, then decelerate and change the flow direction, so that the kinetic energy is converted into potential energy (pressure). In a single-stage centrifugal fan, the gas enters the impeller axially, changes to radial direction when passing through the impeller, and then enters the diffuser. In the diffuser, the gas changes its flow direction and the cross-sectional area of ​​the pipe increases, which slows down the airflow. This deceleration effect converts kinetic energy into pressure energy. The pressure increase mainly occurs in the impeller, and secondly in the expansion process. In a multi-stage centrifugal fan, a return flow device is used to allow the airflow to enter the next impeller to generate higher pressure.

Application

1. Ventilation and induced draft: centrifugal party systems are widely used in boilers and industrial kilns. They mainly play the role of ventilation and induced draft, on the one hand to ensure the environment of the boiler room or industrial kiln, on the other hand to allow the replacement of oxygen-rich air, so that the firepower of the boiler or kiln is more fierce, to a certain extent, saving coal and other power resources, and reducing the production cost of the enterprise.

2. Ventilation, cooling, and dust removal: In the factory, workshops, warehouses and other departments are equipped with centrifugal fans, which play the role of ventilation, ensure the fresh air in the workshop, and help purify the working environment and the health of employees. At the same time, the factory warehouse is equipped with centrifugal fans to dry the air and ensure that the mechanical equipment or other industrial products maintain their original quality.

3. Inflation and propulsion: centrifugal party systems can create artificial air sources in the membrane, shooting or other required air, but there is no natural wind, and the centrifugal fan will use its characteristics to create artificial wind. Centrifugal fans can be inflated to propel inflatable objects such as hovercraft in water or fast hovercraft forward.

centrifugal party systems centrifugal party systems

Company Profile

First of all, the company takes the “Belt and Road” initiative as its guide and implements its “green development” vision. Shandong Aike Group adheres to the business philosophy of “customer first, innovation-driven” and cultivates a corporate culture of “honesty and trustworthiness”.

Secondly, in recent years, its performance has continued to grow and its expansion has been steady. This trajectory has cemented lasting trust among clients and fostered lasting partnerships. In the current tide of economic development and fierce market competition, the company cherishes its hard-won honors. Shandong Aike Group unswervingly follows the road of industrialization and modernization, relies on the diligence and wisdom of “Aike” people, and unswervingly creates products with reliable quality and excellent service.

Finally, Shandong Aike Group is a leading manufacturer dedicated to providing high-quality fans to the world. Shandong Aike Group adheres to a firm commitment to pursuing excellence and specializes in the production of innovative and reliable fans, including axial flow fans, mixed flow fans, roof fans, heaters, etc.
